High Output Tape Light IP54 RGBW 5M Kit

SERIES
PLX-HTL54-RGBW-24V-5MKIT
16.4FT TRULUX KIT HIGH OUTPUT RGB+WW, 4.6W PER FT, 24V,INCL: WIRE, CONNECTIONS, DRIVE
High Output Tape Light IP54 RGBW 5M Kit
High Output Tape Light IP54 RGBW 5M Kit High Output Tape Light IP54 RGBW 5M Kit

Performance

Input Voltage
24V DC
Wattage
4.4 W/ft
CCT
RGBW
CRI
90+
Lumens
240
Cut Increment
6.56 in
Max Run
16.4 ft
Optics (Degree)
120 degrees
Rated Life (Hr)
50,000 Hours
Temperature Range
5C (41F) to 70C (158F) degrees
Dimming
PWM 5 - 100%
Spacing
0.64 Inch

Physical

Weight
2.30 lbs
Width
0.03 Foot
Length
16.4 Foot

Certification

Safety Rating
cULus Listed
IP Rating
IP54
Location Rating
Damp
Indoor
Y
Outdoor
Y
Item Number Length Input Voltage CCT CRI Wattage Lumens Max Run IP Rating UOM
PLX-HTL54-RGBW-24V-5MKIT 16.4 Foot 24V DC RGBW 90+ 4.4 W/ft 240 16.4 ft IP54 Each
