High Output COB Tape Light IP54 RGBW Custom Cut

SKU
PLX-HTL54-COB-RGBW-24V-CC
Custom Cut HTL COB Tape Light, IP54, 3.28" cut increment, RGBW, 4.5W/ft
High Output COB Tape Light IP54 RGBW Custom Cut
High Output COB Tape Light IP54 RGBW Custom Cut

Performance

Input Voltage
24V DC
Wattage
4.5 W/ft
CCT
RGBW
CRI
90+
Lumens
200
Cut Increment
1.97 in
Max Run
16.4 ft
Optics (Degree)
120 degrees
Rated Life (Hr)
50,000 Hours
Temperature Range
5C (41F) to 70C (158F) degrees
Dimming
TRIAC / ELV 5 - 100%

Physical

Weight
0.04 lbs
Length
Custom Cut

Certification

Safety Rating
cULus Listed
IP Rating
IP54
Location Rating
Damp
Indoor
Y
Outdoor
Y
Item Number Length Input Voltage CCT CRI Wattage Lumens Max Run IP Rating UOM
PLX-HTL54-COB-RGBW-24V-CC Custom Cut 24V DC RGBW 90+ 4.5 W/ft 200 16.4 ft IP54 Foot
