High Output COB Tape Light 4000K 16.4Ft Pro Kit

SERIES
PLX-HTL20-COB-40K-24V-PRO
High Output COB Tape Light 4000K 16.4Ft Pro Kit
High Output COB Tape Light 4000K 16.4Ft Pro Kit

Performance

Input Voltage
24V DC
Wattage
5 W/ft
CCT
4000K
CRI
90+
Lumens
460
Cut Increment
1.97 in
Max Run
16.4 ft
Optics (Degree)
120 degrees
Rated Life (Hr)
50,000 Hours
Temperature Range
5C (41F) to 70C (158F) degrees
Dimming
TRIAC / ELV 5 - 100%
Style
2Pin

Physical

Weight
4.20 lbs
Width
0.03 Foot
Length
16.4 Foot

Certification

Safety Rating
cULus Listed
IP Rating
IP20
Location Rating
Dry
Indoor
Y
Item Number Length Input Voltage CCT CRI Wattage Lumens Max Run IP Rating UOM
PLX-HTL20-COB-40K-24V-PRO 16.4 Foot 24V DC 4000K 90+ 5 W/ft 460 16.4 ft IP20 Each
