Channel Ray RGBW SPI Pixel 12v DC

SKU
PLX-CR365-PXLSPI-RGBW-12V
LED Channel Ray, SMD 5050 RGB IC LED x3, 20pcs per string, 12VDC
Channel Ray RGBW SPI Pixel 12v DC
Channel Ray RGBW SPI Pixel 12v DC

Performance

Input Voltage
12V DC
UV Inhibitor
N
Wattage
0.76 W/module
CCT
RGB
Lumens
50
Cut Increment
3.3 in
Max Run
20 units
Optics (Degree)
160 degrees
Rated Life (Hr)
50,000 Hours
Temperature Range
-25C (-13F) to 60C (140F) degrees
Dimming
SPI TM1923
Finish
White
Spacing
3.3 Inch

Physical

Weight
0.65 lbs
Width
0.68 Inch
Length
140.6 Inch
Height
0.32 Inch

Certification

Safety Rating
cURus Recognized
IP Rating
IP65
Location Rating
Damp
Indoor
Y
Outdoor
Y
ROHS
Y
Item Number Length Input Voltage CCT Wattage Lumens Max Run IP Rating UOM
PLX-CR365-PXLSPI-RGBW-12V 140.6 Inch 12V DC RGB 0.76 W/module 50 20 units IP65 Each
