Microlux Static White
SERIES
C-PLX-MLUX
Featuring fully encased tape light, MicroLux provides smooth evenly diffused light that eliminates the needs for additional extrusion housings and lenses. With light emitting from three sides, MicroLux is a unique product that can be used in small spaces, or be placed on in direct view to meet the needs of dynamic lighting installations.
Performance
Input Voltage
24V DC
CCT
3000K / 4000K
Finish
White
Wattage
4.4W/ft
Optics (Degree)
120 Degrees
Cut Increment
3.94 Inch
Max Run
16.4ft
Rated Life (Hr)
30,000 Hours
Temperature Range
-20°C (-4°F) to 40°C (104°F)
Dimming
Dimmable (5-100%) with most ELV, TRIAC dimmers
Lumens
370-375Lm/ft
Certification
Safety Rating
cULus Listed
IP Rating
IP65
Location Rating
Wet
Indoor
Y
Outdoor
Y
| Item Number | Length | Input Voltage | CCT | CRI | Wattage | Lumens | Max Run | IP Rating | UOM |
|---|---|---|---|---|---|---|---|---|---|
| PLX-MLUX-30 | 16.4 Foot | 24V DC | 3000K | 90+ | 4.4 W/ft | 370 | 16.4 ft | IP65 | Each |
| PLX-MLUX-40 | 16.4 Foot | 24V DC | 4000K | 90+ | 4.4 W/ft | 375 | 16.4 ft | IP65 | Each |
